1
Engine displacement
125
2
Model
SCARABEO
3
Year
2007
4
Trim
Scarabeo Light Carb.
5
Parts Catalog
Exhaust unit
6
Parts Diagram
Parts Catalog
Water cooler
by
Front body - Front shield
Exhaust unit
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
Silencer
872871
£955,58 Unit Price incl. VAT
1
Silencer
848270
Not Available
1
Silencer
JC14310X92010
Not Available
2
Exhaust pipe protection
JC14781X92000
£67,64 Unit Price incl. VAT
3
screw
JC14783X92000
£1,30 Unit Price incl. VAT
4
Washer
JCD11200500RN00
Not Available
5
Insulating washer
JC14782X92000
£3,35 Unit Price incl. VAT
6
Exhaust pipe
JC14320X93000
Not Available
6
Exhaust pipe
JC14320X92010
£323,04 Unit Price incl. VAT
6
Exhaust pipe
JC14320X92000
£127,02 Unit Price incl. VAT
7
Nut
JCB20100800JN00
Not Available
8
Exhaust pipe gasket
JC14181X92000
£1,16 Unit Price incl. VAT
9
Hose clamp
JC14190X92000
£31,70 Unit Price incl. VAT
10
Bushing
JC14182X92000
Not Available
11
Exhaust pipe support clamp
JC61511X92000
Not Available
12
Bearing 6004-2RS D20x42x12
AP8128186
Not Available
13
screw M8x70
JCC20108070JN00
£3,26 Unit Price incl. VAT
14
Washer
JCD10200800JN00
£2,41 Unit Price incl. VAT
15
Nut M8
JCB56100800JN00
£2,12 Unit Price incl. VAT
16
screw M8x30
JCA20108030JN00
£0,67 Unit Price incl. VAT
17
Heat protection
JC14786X92000
£26,53 Unit Price incl. VAT

Find the detailed :label MOTO GUZZI LAVERDA SCARABEO diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original MOTO GUZZI LAVERDA SCARABEO part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
