1
Engine displacement
850
2
Model
V9
3
Year
2020
4
Trim
V9 Bobber Sport 850 Euro 4 ABS
5
Parts Catalog
Gear selector
6
Parts Diagram
Parts Catalog
TAIL LIGHTS
by
SHOCK ABSORBER
Gear selector
1
2
3
4
5
6
7
8
9
10
11
12
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
25
1
Lever rubber
AP8120912
£3,68 Unit Price incl. VAT
2
Rubber pedal
2B004062
£30,92 Unit Price incl. VAT
3
Complete gearchange lever
2B004053
£264,94 Unit Price incl. VAT
4
screw TSPEI IX M8X25
2B004112
£0,30 Unit Price incl. VAT
5
Piastra pedana pilota sx
2B004043
£122,69 Unit Price incl. VAT
6
Spring washer
GU95129260
£2,59 Unit Price incl. VAT
7
Left ball joint M6
898397
£16,18 Unit Price incl. VAT
8
Nut M6
GU03256800
£1,26 Unit Price incl. VAT
9
Tirante comando cambio cpl.
2B004109
£37,15 Unit Price incl. VAT
10
Nut M6
GU92609206
£2,47 Unit Price incl. VAT
11
Levier de vitesses
2B004348
£109,43 Unit Price incl. VAT
12
Dado autobloccante M6x1
GU92630206
£2,48 Unit Price incl. VAT
13
Hex socket screw
GU98692318
£1,02 Unit Price incl. VAT
14
RH ball joint M6
898396
£16,46 Unit Price incl. VAT
15
Lever pin
2B001009
£23,92 Unit Price incl. VAT
16
Left ball joint M6
AP8110053
£16,18 Unit Price incl. VAT
17
Nut
AP8152138
£1,88 Unit Price incl. VAT
18
Gear control tie rod
2B001941
£24,13 Unit Price incl. VAT
19
Nut M6
AP8150026
£0,96 Unit Price incl. VAT
20
RH ball joint M6
AP8210007
£15,91 Unit Price incl. VAT
21
screw
GU98632322
£1,02 Unit Price incl. VAT
22
Washer 6,4x12
GU03013800
£1,98 Unit Price incl. VAT
23
Shift lever
GU20258221
£73,70 Unit Price incl. VAT
24
Spring washer 14,5x24
AP8150471
£4,14 Unit Price incl. VAT
25
Shift lever
GU20258221
£73,70 Unit Price incl. VAT

Find the detailed :label MOTO GUZZI LAVERDA SCARABEO diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original MOTO GUZZI LAVERDA SCARABEO part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
