CRANK-CASE FOR SCARABEO SCARABEO 2T E2 NET 2010

Cylinder head / Carburettor

Item numbers
Crank-case SCARABEO SCARABEO-SCOOTER 50 SCARABEO 2010 Scarabeo 2T E2 NET
1
2
2
3
4
5
6
7
8
9
10
10
11
12
12
13
14
15
16
16
17
1
CRANK-CASE

CM1275015  

Unit Price Incl. Tax

2
CYLINDER STUD
CYLINDER STUD

239382  

1A003633R

Unit Price Incl. Tax

3
NUT

020006  

Contact
4
RING

287223  

Unit Price Incl. Tax

5
RING

113533  

Unit Price Incl. Tax

6
NUT M8

020008  

Contact
7
SHOCK ABSORBER CONNECTION SILENT BLOCK

267823  

Unit Price Incl. Tax

8
SPACER

266625  

Unit Price Incl. Tax

9
SCREW W/ FLANGE
FLAGED HEXAGONAL HEAD SCREW

414835  

B017632

Unit Price Incl. Tax

10
SILENT-BLOCK

266773  

Unit Price Incl. Tax

11
ENGINE SET GASKET

494579  

Contact
12
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price Incl. Tax

13
GASKET RING

478498  

Unit Price Incl. Tax

14
CIRCLIP

006647  

Contact
15
BEARING 20X47X14

434735  

Unit Price Incl. Tax

16
LOCATING DOWEL
REFERENCE DOWEL

478115  

B015957

Unit Price Incl. Tax

17
PLUG

851726  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Crank-case of your SCARABEO Scarabeo 2T E2 NET of SCARABEO. Let us know if you have any questions.
