Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Variator - Transmission final drive

CARBURETTOR - OIL PUMP ASSY. FOR SCARABEO SCARABEO 2T (ENGINE MINARELLI) 1998

Acc. - Mechanics anti-theft

Item numbers
Carburettor - oil pump assy. SCARABEO SCARABEO-SCOOTER 50 SCARABEO 1998 Scarabeo 2T (engine Minarelli)
1
2
2
3
4
5
6
6
6
7
8
9
10
11
12
13
1
SCREW M6X20

AP8502564  

Unit Price Incl. Tax

2
INTAKE MANIFOLD

AP8206466  

Contact
2
INTAKE MANIFOLD D12

AP8206565  

Contact
3
REED VALVE ASSY

AP8206557  

Contact
4
FUEL INTAKE VALVE GASKET

AP8206486  

Contact
5
HOSE COLLAR

AP8206181  

Contact
6
CARBURETTOR PHBN 12-GS

AP8206803  

Contact
6
CARBURETTOR PHBN 12-GS

AP8206807  

Contact
6
CARBURETTOR PHBN 12-GS

AP8206808  

Contact
7
CARBURETTOR GUARD

AP8206473  

Contact
8
HOSE CLAMP

AP8206711  

Contact
9
OIL PUMP ASSY.

AP8206467  

Contact
10
SCREW

AP8508887  

Contact
11
UNION+BREATHER PIPE 10X14X210

AP8206131  

Contact
12
GASKET 8, 2X15X1, 2

AP8206488  

Contact
13
SCREW W/ FLANGE M8X15

AP8206203  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Carburettor - oil pump assy. of your SCARABEO Scarabeo 2T (engine Minarelli) of SCARABEO. Let us know if you have any questions.

Genuine parts for SCARABEO Scarabeo 2T (engine Minarelli) 1998
