FUEL VAPOUR RECOVER SYSTEM FOR SCARABEO SCARABEO E2 (ENGINE PIAGGIO) 2006

Ignition unit I

Item numbers
Fuel vapour recover system SCARABEO SCARABEO-SCOOTER 250 SCARABEO 2006 Scarabeo E2 (engine Piaggio)
1
2
3
4
5
6
7
7
8
8
9
9
9
10
11
12
13
13
14
15
16
17
18
19
20
1
3-WAY UNION

AP8120116  

Unit Price Incl. Tax

2
3-WAY UNION

AP8102727  

Unit Price Incl. Tax

3
"PURGE" VALVE

AP8106776  

Unit Price Incl. Tax

4
VALVE SUPPORT CLAMP

AP8134650  

Unit Price Incl. Tax

5
VALVE SUPPORT CLAMP

AP8146971  

Contact
6
CARBON FILTER

AP8102678  

Unit Price Incl. Tax

7
HOSE CLAMP D8

AP8120179  

Unit Price Incl. Tax

8
FUEL PIPE 5, 5X10
CONNECTING PIPE

AP8120952  

896544

Unit Price Incl. Tax

9
BREATHER PIPE 4X8
PIPE (NOT METALLIC)

AP8220263  

896570

Unit Price Incl. Tax

10
CLIP M5

AP8102375  

Unit Price Incl. Tax

11
HOSE CLAMP

AP8102520  

Unit Price Incl. Tax

12
SCREW W/ FLANGE M5X15

AP8152273  

Unit Price Incl. Tax

13
HOSE CLAMP D10, 1

AP8101595  

Unit Price Incl. Tax

14
HOSE CLAMP D.76

AP8102688  

Unit Price Incl. Tax

15
HOSE CLAMP D.80, 5

AP8102719  

Unit Price Incl. Tax

16
SCREW W/ FLANGE

AP8152283  

Unit Price Incl. Tax

17
DASHBOARD BUSH

AP8121741  

Unit Price Incl. Tax

18
SCREW W/ FLANGE M6X25

AP8152280  

Unit Price Incl. Tax

19
SELF-LOCKING NUT M6

AP8152299  

Unit Price Incl. Tax

20
SPRING PLATE M6
SPRING PLATE (M6)

AP8102376  

254485

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Fuel vapour recover system of your SCARABEO Scarabeo E2 (engine Piaggio) of SCARABEO. Let us know if you have any questions.
