Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Front body - Front fairing

FRONT BODY - FRONT MUDGUARD FOR SCARABEO SCARABEO E3 (ENGINE PIAGGIO) 2006

Front body - Front shield

Item numbers
Front body - Front mudguard SCARABEO SCARABEO-SCOOTER 200 SCARABEO 2006 Scarabeo E3 (engine Piaggio)
1
1
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
14
14
1
AP8156306
UPPER FRONT MUDGUARD, RED

AP8156306  

Contact
1
AP8156312
UPPER FRONT MUDGUARD, BLUE

AP8156312  

Contact
1
AP8156314
UPPER FRONT MUDGUARD, GREY

AP8156314  

Contact
2
CHIUSURA SCUDO ANT.NERO
CHIUSURA SCUDO ANT.NERO

AP8139605  

Contact
3
LH HUB COVER, GREY

AP8156132  

Contact
4
RH HUB COVER, GREY

AP8156131  

Contact
5
FRONT MUDGUARD CONNECT.

AP8134489  

Unit Price Incl. Tax

6
RUBBER W/ INSERT

AP8120531  

Unit Price Incl. Tax

7
SPRING PLATE M6
SPRING PLATE (M6)

AP8102376  

254485

Unit Price Incl. Tax

8
CABLE-GUIDE

AP8144240  

Contact
9
SCREW W/ FLANGE
SCREW

AP8152278  

598839

Unit Price Incl. Tax

10
RUBBER SPACER

AP8120001  

Unit Price Incl. Tax

11
SCREW 5, 5X15, 9*

AP8150426  

Unit Price Incl. Tax

12
WASHER 8, 4X16X1, 6

AP8150017  

Unit Price Incl. Tax

13
HEX SOCKET SCREW M8X40
HEXAGONAL SOCKET HEAD SCREW

AP8150171  

149104

Unit Price Incl. Tax

14
AP8156307
BOTTOM FRONT MUDGUARD, RED

AP8156307  

Contact
14
AP8156313
LOWER FRONT MUDGUARD, BLUE

AP8156313  

Contact
14
AP8156315
LOWER FRONT MUDGUARD, GREY

AP8156315  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Front body - Front mudguard of your SCARABEO Scarabeo E3 (engine Piaggio) of SCARABEO. Let us know if you have any questions.
