Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Cylinder

CYLINDER HEAD FOR SCARABEO SCARABEO IE LIGHT 2009

Drive shaft

Item numbers
Cylinder head SCARABEO SCARABEO-SCOOTER 125 SCARABEO 2009 Scarabeo IE Light
1
1
2
3
3
4
5
6
7
7
8
8
9
9
10
11
12
13
14
15
16
16
17
18
19
20
20
21
22
1
CYLINDER HEAD ASSY.

JC11A00X05300  

Unit Price Incl. Tax

1
CYLINDER HEAD ASSY.

JC11A00X05400  

Unit Price Incl. Tax

2
EXHAUST PIPE STUD BOLT

AP3BAN000246  

Unit Price Incl. Tax

3
CYLINDER HEAD GASKET

82893R  

Unit Price Incl. Tax

3
CYLINDER HEAD GASKET

854795  

Contact
4
SCREW

AP4ADN000014  

Unit Price Incl. Tax

5
SCREW M8X166

AP3ADN000115  

Unit Price Incl. Tax

6
SCREW M6X130

AP4ABN000117  

Unit Price Incl. Tax

7
WASHER

AP3EEN000234  

Unit Price Incl. Tax

8
INTAKE VALVE

AP3CLA000636  

Contact
8
INTAKE VALVE

AP3CLA000638  

Unit Price Incl. Tax

9
EXHAUST VALVE

AP3CLA000637  

Unit Price Incl. Tax

9
EXHAUST VALVE

AP3CLA000639  

Unit Price Incl. Tax

10
VALVE STEM SEAL

854563  

Unit Price Incl. Tax

11
SPRING

AP3CHA000237  

Unit Price Incl. Tax

12
UPPER CUP

AP3CGA000635  

Unit Price Incl. Tax

13
HALF-CUNE

AP3CIA000238  

843338

Unit Price Incl. Tax

14
BUSH

AP3FCN000128  

Unit Price Incl. Tax

15
LOCATING DOWEL 8X10

AP3FCN000127  

Unit Price Incl. Tax

16
SCREW M6X40

AP4ADN000248  

Unit Price Incl. Tax

17
BULBE DE TEMPÉRATURE D’EAU
WATER TEMPERATURE SENSOR

640485  

1A021287R

Unit Price Incl. Tax

18
THERMOSTAT
THERMOSTAT

82831R  

82831R5

Unit Price Incl. Tax

19
THERMOSTAT COVER

AP3BAA000207  

Unit Price Incl. Tax

20
SPACER 6X8X6, 8

AP3FCN000250  

Unit Price Incl. Tax

21
BREATHER PIPE UNION

JC11121X05300  

Unit Price Incl. Tax

22
THERMOSTAT GASKET

504305  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Cylinder head of your SCARABEO Scarabeo IE Light of SCARABEO. Let us know if you have any questions.
