ELECTRICAL SYSTEM II FOR SCARABEO SCARABEO E2 (ENGINE PIAGGIO) 2003

Exhaust unit

Item numbers
Electrical system II SCARABEO SCARABEO-SCOOTER 125 SCARABEO 2003 Scarabeo E2 (engine Piaggio)
1
2
3
4
5
6
7
8
9
10
1
MAIN WIRING HARNESS

AP8127430  

Contact
2
HT COIL
H.T. COIL

AP8580123  

Contact
3
BATTERY LEADS-ENGINE

AP8127431  

Contact
4
RELAY 12V-150A
RELAY 12V-150A

AP8124636  

AP81129275

Unit Price Incl. Tax

5
RELAY-STARTER MOTOR CABLE

AP8124935  

Unit Price Incl. Tax

6
NUT M6

AP8150026  

Unit Price Incl. Tax

7
CURVED SPRING WASHER 6X12
WASHER, WAVE

AP8150429  

Contact
8
H.V. CABLE
H.T. CABLE

AP8127311  

Contact
9
SCREENED CAP
CAP

AP8550455  

293845

Unit Price Incl. Tax

10
SPARK PLUG PROT.COLLAR
CLAMP

AP8580152  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Electrical system II of your SCARABEO Scarabeo E2 (engine Piaggio) of SCARABEO. Let us know if you have any questions.
