CONNECTING ROD GROUP FOR SCARABEO SCARABEO (ENGINE MINARELLI) 2000

Covers

Item numbers
Connecting rod group SCARABEO SCARABEO-SCOOTER 100 SCARABEO 2000 Scarabeo (engine Minarelli)
1
2
2
3
4
5
6
7
8
9
9
10
11
12
1
CRANKSHAFT CPL.

AP8510792  

Contact
2
SCREW M6X12

AP8510836  

Contact
3
CONNECTING ROD CPL.

AP8510779  

Contact
4
OIL SEALS - SET

AP8510796  

Contact
5
PIN CAGE

AP8510630  

Contact
6
OIL SEAL RETAINER PLATE

AP8510812  

Contact
7
OIL SEAL RETAINER PLATE

AP8510814  

Contact
8
FLYWHEEL MAGNETO KEY

AP8206182  

Unit Price Incl. Tax

9
BEARING

AP8510840  

Contact
10
OIL SEAL

AP8510715  

Contact
11
OIL SEAL

AP8510654  

Contact
12
SPACER

AP8510830  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Connecting rod group of your SCARABEO Scarabeo (engine Minarelli) of SCARABEO. Let us know if you have any questions.
