CARBURETTOR FOR SCARABEO SCARABEO (ENGINE MINARELLI) 2000

Central crank-case set

Item numbers
Carburettor SCARABEO SCARABEO-SCOOTER 100 SCARABEO 2000 Scarabeo (engine Minarelli)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
1
CARBURETTOR CPL.

AP8106740  

Contact
2
CARBURETTOR CAP

AP8510597  

Contact
3
VITE ARIA MIN.CON ROSETTA
VITE ARIA MIN.CON ROSETTA

AP8510740  

Contact
4
GAS VALVE ADJ.SCREW CPL.

AP8510741  

Contact
5
VALVE GAS RETURN SPRING

AP8510742  

Contact
6
CONICAL PIN CPL.

AP8510743  

Contact
7
GAS VALVE

AP8510744  

Contact
8
SCREW

AP8510745  

Contact
9
IDLE JET

AP8510746  

Contact
10
NEEDLE VALVE

AP8510747  

Contact
11
MAIN JET

AP8510748  

Contact
12
SCREW

AP8510749  

Contact
13
COVER

AP8510750  

Contact
14
AUTOMATIC STARTER CPL.

AP8510751  

Unit Price Incl. Tax

15
CONICAL PIN VALVE CPL.

AP8510752  

Contact
16
PIN

AP8510753  

Contact
17
SCREW

AP8510754  

Contact
18
GASKET

AP8510755  

Contact
19
NUT

AP8510756  

Contact
20
FLOAT

AP8510760  

Contact
21
O-RING

AP8510761  

Contact
22
O-RING

AP8510762  

Contact
23
SCREW

AP8510763  

Contact
24
PLATE

AP8234209  

Contact
25
CAP

AP8222795  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from SCARABEO. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Carburettor of your SCARABEO Scarabeo (engine Minarelli) of SCARABEO. Let us know if you have any questions.
