1
Engine displacement
350
2
Model
V35
3
Year
1986
4
Trim
V 35 II
5
Parts Catalog
Drive shaft
6
Parts Diagram
Parts Catalog
Exhaust unit
by
Gear box
Drive shaft
1
2
3
4
6
7
7
8
9
10
11
12
13
14
15
16
17
18
1
Crankshaft cpl.
GU19064121
Not Available
2
Cover
GU19065400
£13,62 Unit Price incl. VAT
3
Connecting rod
GU19061521
£414,71 Unit Price incl. VAT
4
screw
GU19062221
Not Available
6
Bearing half-shell
GU19062022
£57,68 Unit Price incl. VAT
7
Front main half-bearing
GU19065623
£61,20 Unit Price incl. VAT
8
Rear main half-bearing
GU19066522
£272,05 Unit Price incl. VAT
9
Shoulder
GU31066480
Not Available
10
Piston
GU19060421
Not Available
11
Piston ring
GU19060700
£83,65 Unit Price incl. VAT
12
Piston ring
GU19061000
Not Available
13
Piston pin
GU19061220
Not Available
14
Stop ring
GU19061320
Not Available
15
Pistonring set
GU19060600
Not Available
16
Bushing
GU19061821
£30,20 Unit Price incl. VAT
17
screw
GU19067700
£2,51 Unit Price incl. VAT
18
Washer 8,4X13X0,8
GU14615901
£2,48 Unit Price incl. VAT

Find the detailed Drive shaft MOTO GUZZI LAVERDA SCARABEO diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original MOTO GUZZI LAVERDA SCARABEO part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
