1
Engine displacement
350
2
Model
NEVADA
3
Year
1993
4
Trim
Nevada
5
Parts Catalog
Rear wheel
6
Parts Diagram
Parts Catalog
Front wheel
by
Front shock absorber
Rear wheel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
Rear wheel(complete)
GU31630365
Not Available
2
Brake disc
GU31613380
Not Available
2
Rear brake disc
GU27613311
Not Available
3
Hex socket screw
GU98622425
£6,13 Unit Price incl. VAT
4
RH rubber coupling
GU19632501
£15,76 Unit Price incl. VAT
5
LH rubber coupling
GU19632502
£13,22 Unit Price incl. VAT
6
Bearing
GU92204218
£73,26 Unit Price incl. VAT
7
Bearing
GU92204217
£60,25 Unit Price incl. VAT
8
Spacer
GU27633910
£52,58 Unit Price incl. VAT
9
Spacer
GU27356910
£9,01 Unit Price incl. VAT
10
Rear wheel spindle
GU31633330
Not Available
11
Washer
GU14634400
Not Available
12
Nut M6x1,5
GU92602316
£1,45 Unit Price incl. VAT
13
Long spoke
GU23631470
£9,91 Unit Price incl. VAT
14
Short spoke
GU23631170
£9,94 Unit Price incl. VAT
15
Nipples
GU27631250
£2,84 Unit Price incl. VAT
16
Counterweight 20 g
GU12616102
£4,02 Unit Price incl. VAT
16
Counterweight 15 gr.
GU12616101
£4,02 Unit Price incl. VAT
16
Counterweight 30 g
GU12616103
£8,27 Unit Price incl. VAT
17
Rear wheel 250x16"
GU23630770
£446,50 Unit Price incl. VAT

Find the detailed Rear wheel MOTO GUZZI LAVERDA SCARABEO diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original MOTO GUZZI LAVERDA SCARABEO part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
