1
Engine displacement
1200
2
Model
NORGE
3
Year
2014
4
Trim
Norge IE 8V Polizia Stradale
5
Parts Catalog
Head cover
6
Parts Diagram
Parts Catalog
Rear brake caliper
by
Dashboard
Head cover
1
2
2
3
3
4
4
5
5
6
7
8
8
9
9
9
9
10
11
12
13
14
15
15
1
RH Head cover
880124
£262,08 Unit Price incl. VAT
2
Special screw
976591
£7,78 Unit Price incl. VAT
3
Damper drift
879975
Not Available
4
Spark plug cover
883493
£17,82 Unit Price incl. VAT
5
Hex socket screw
GU98230510
£1,02 Unit Price incl. VAT
6
RH Name plate "Moto Guzzi"
976560
£26,88 Unit Price incl. VAT
7
RH gasket
872742
£17,89 Unit Price incl. VAT
8
Spark plug pipe
879987
£13,20 Unit Price incl. VAT
9
O-ring 26X2,5
873626
£5,08 Unit Price incl. VAT
10
LH Head cover
880123
£262,08 Unit Price incl. VAT
11
LH gasket
872741
£17,89 Unit Price incl. VAT
12
LH Name plate "Moto Guzzi"
976559
£26,88 Unit Price incl. VAT
13
RH cover
873654
£20,26 Unit Price incl. VAT
14
LH cover
872740
£15,19 Unit Price incl. VAT
15
Gasket
880127
£7,07 Unit Price incl. VAT

Find the detailed :label MOTO GUZZI LAVERDA SCARABEO diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original MOTO GUZZI LAVERDA SCARABEO part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
