Front/rear shock absorber for MOTO GUZZI LAVERDA SCARABEO California III Carburatori from 1990

Free shipping for all orders to United Kingdom over £150! See conditions.

Front seat 1st-2nd series

Front/rear shock absorber

1

Front fork

GU29490252

Not Available

2

Plug

GU18513460

£15,96 Unit Price incl. VAT

3

Stem plug washer

GU18513560

£2,12 Unit Price incl. VAT

4

Cup

GU14494600

Not Available

5

Tap.roller bearing

GU92249225

£80,94 Unit Price incl. VAT

6

Clearance washer

GU14516700

£22,25 Unit Price incl. VAT

7

Dust cover

GU14517000

£7,92 Unit Price incl. VAT

8

Bracket

GU29531850

Not Available

9

Bracket

GU29531050

Not Available

10

Steering shock absorber

GU17530260

Not Available

11

screw

GU98054325

Not Available

12

Washer

GU95001205

£1,64 Unit Price incl. VAT

13

Nut

GU92602206

£1,68 Unit Price incl. VAT

14

Spring washer 8x15x0,3

GU61270300

£1,70 Unit Price incl. VAT

15

screw

GU98230816

£1,58 Unit Price incl. VAT

16

Stabilization plate

GU29436650

Not Available

17

screw

GU98230816

£1,58 Unit Price incl. VAT

18

O-ring

GU90706092

£0,89 Unit Price incl. VAT

19

Bush

GU29436450

£2,06 Unit Price incl. VAT

20

Rubber spacer

GU93110060

£1,09 Unit Price incl. VAT

21

Pin

GU29439550

Not Available

22

Rear shock absorber

GU28550240

Not Available

23

Pin

GU29541850

Not Available

24

Washer

GU95100535

£1,68 Unit Price incl. VAT

25

Washer

GU95100239

£2,04 Unit Price incl. VAT

26

Top screw

GU98230822

Not Available

26

screw

GU98230840

£4,63 Unit Price incl. VAT

27

Guard

GU29751350

Not Available

28

Turn indicator support grill

GU23505810

Not Available

29

Pin

GU23922210

£1,33 Unit Price incl. VAT

30

Trademark sticker

GU28769533

Not Available

31

screw

GU28576047

£9,26 Unit Price incl. VAT

32

Bracket

GU29578800

£2,27 Unit Price incl. VAT

33

Hex screw

GU98054316

£0,49 Unit Price incl. VAT

34

Washer

GU95001206

Not Available

Find the detailed Front/rear shock absorber MOTO GUZZI LAVERDA SCARABEO diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original MOTO GUZZI LAVERDA SCARABEO part number.

The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
